Portable Ground Station with Built-in Monitor for DJI Mavic

Patented
30 Day Warranty
Categories: , , , , , , ,

This product has been discontinued Replacement:

Battery Powered Mobile Monitor Station
Portable Ground Station with Built-in Monitor for DJI Mavic
left_angled
Right_Angled
truck_view
Right_Zoomed
side_view
top_overview
Top_Zoomed
se920-handle-up
se920-bk-17
Case Closed Dimensions
seahorse_920_big61
seahorse_920_big71
seahorse_920_big91

Description

Case Club is proud to introduce the Drone Ground Station for DJI Mavic drones. We took special care in engineering the features that this case has to offer. From the adjustable lid stays to the easy to access controller & drone, this case has it all! Case Club’s goal is to be efficient and also user friendly in what we engineer, and this Drone Ground Station will protect your valuable DJI Mavic Drone, controller, and equipment in the field. The case is molded from tough polypropylene and is both rugged & lightweight. A Perimeter O-Ring helps keep out the elements, protecting the contents from water, dust and other contaminants. The Case Club Drone Ground Station Case for the DJI Mavic is one-of-a-kind and is the only product that gives users a 24″ live drone-vision view while in the field!

Portable Ground Station with Built-in Monitor - Features

Special Case Features

  • View Drone Feed on a 24" High Definition Monitor
  • Large screen allows multiple people to easily view the drone feed at the same time
  • Can Deploy Drone in Under 2 Minutes
  • Self Contained power supply will power everything for 2.5 hours
  • Lid Stays can Adjust Viewing Angle
  • Stores Drone and Controller in easy-to-grab fashion
  • Extension Handle and Wheels for easy Transport
  • Reinforced Padlock holes
  • Case is Waterproof & Airtight
  • Not intended for airline checked luggage or shipping which can damage the monitor
  • Works wirelessly with standard (cell phone holding) controller. DJI Smart Controller must be wired in.
  • Please allow 5-10 business days to ship

Case Includes

  • 24" Built in Full HD Display (prewired)
  • Apple TV (prewired)
  • Battery Power Supply (prewired)
  • Pre cut Military grade PE foam in base
  • Setup Instructions

Items NOT Included

  • Mavic Drone, Drone Batteries, Drone Controller, Drone Accessories
  • iPhone, iPhone Accessories

Hardware Compatibility

  • iPhone 8 & Newer (specifically iPhones compatible with Apple TV)
  • HDMI can be disconnected from Apple TV for a direct connection to monitor
  • All DJI Mavic Models

Monitor Specifications

Resolution1920 X 1080
Refresh Rate144HZ
Response Time1MS
Eye Care TechnologyYes
Color Support16.7 Million

Additional Monitor Specs

Panel TypeTN
AntiglareYes
Power Requirnment90 - 264 VAC, 47 - 63 Hz
Power Consumption 21W Typ, 34W Max, 0.5W sleep/off, 0.3W switch-off

Case Meets or Exceeds Military Specifications

  • IPX7 & MIL-STD810F 512.4 Certification
  • IP6X Letter of Certification
  • Material Safety Data Sheet (MSDS)
  • IP, NEMA Explained

Industry Uses

  • Emergency Services
  • Military
  • Commercial
  • Hobby
  • Agriculture
  • Real Estate
  • Construction
  • Surveying
  • Boating & Offroading

Case Weights

  • Case Fully Loaded is 35LBS
  • Case Empty is 25LBS

Power Supply Specifications

  • At full charge, 2.5 Hours of supplied local power for monitor and Apple TV
  • AC wall adapter and car charger
  • AC/ DC/ USB OUTPUTS
  • 110 AC output (200W)
  • 2 DC output
  • 2 Quick Charge 3.0 USB ports and 1 USB port (2.4A auto)
  • 151Wh (40800mAh)
  • Power station is equipped with a lithium battery pack, it can be charged by a 15-24 volt solar panel (not included)

Product Specifications

Interior Dimensions22.24"L x 13.66"W x 8.49"H
(565mm x 347mm x 215.646mm)
Exterior Dimensions23.97"L x 16.00"W x 10.10"H
(609mm x 406mm x 257mm)
I.D. Lid/Base Split2.24"Lid / 6.25"Base
(57mm / 159mm)
Shipping Weight25.00 LBS (estimated weight of the product with packaging such as a cardboard box)
(11.34 kg)
Characteristics30 Day Warranty, Waterproof, Outdoor Use
HardwareWheels (Tilt Wheels), Padlockable, Hinged Lid, Pressure Equalization Valve
Case MaterialPlastic
Manufacturing OriginUnited States of America
Manufacturing MethodPrecision Cut, Injection Molded
Monitor Resolution 1080p
Extended TitleIOS Apple Compatible

Customer Questions

  1. Q Is this compatible with other DJI drones? The phantom 4 pro V2 specifically. We have the GL300K r... answer now
    Asked by Jacob S on November 21, 2023 8:03 am
    Answered by the admin This is only compatible with the DJI Mavic.
